AR-135 residential elevator

CONTACT OUR TEAM

Description

This residential elevator model is the hydraulic version of our cable model (AR 130). Quiet and reliable, this elevator for individuals with reduced mobility offers safe access to all types of buildings. Aesthetically pleasing, this lifting platform adds a touch of elegance to your décor. Alternatively, you can select a discrete finish so that the elevator fits in inconspicuously.

Cost

Variable. Contact us for your personnalized quotation.

Delivery time

From 4 to 6 weeks following plan approval.

Installation time

From 4 to 5 days.

ascenseur-AR-135

Additional equipment information

Maximum capacity: one person in a wheelchair and one helper
Maximum load: 340 kg (750 lb)
Drive type: cable-assisted hydraulic
Motor: AC, 120 volts
Nominal speed: 0.12 m/s (24 ft/m)
Maximum travel: 7,000 mm (276 in)
Brakes: parachute type
Emergency lighting
Controller
CSA LR45147 certification
Special features
Industrial Télémécanique controller and panel
Stronger (Delrin) bearings
Anti-skid floor surface
QUICK DELIVERY
FAST INSTALLATION
PERSONALIZED INTERIOR
Ideal for half-cabs
Applicable standard
CSA/B613-09
Equipment category
Interior residential elevator
Vertical, closed shaft

Type of vehicle
One person in a wheelchair
Floor dimensions:
860 mm x 1,370 mm (34 in x 54 in)
One person in a wheelchair and one helper
Floor dimensions:
860 mm x 1,520 mm (34 in x 60 in)
Maximum floor dimensions:
915 mm x 1,525 mm (36 in x 60 in)
